| Model | MP5300 |
|---|---|
| Design | Integrated all-in-one (digestion + colorimetric + electrode built-in) |
| Dimensions / Weight | 480 × 215 × 218 mm / ~11 kg |
| Digester | Built-in dual-zone 8-hole digester |
| Digestion Temperature Range | Room temperature ~ 200°C |
| Built-in Digestion Programs | CODcr (2 h), CODcr (fast), CODMn, total phosphorus, total nitrogen, urea, custom |
| Over-temperature Protection | ≥200°C auto power-off |
| Heating Power | 115W × 2 |
| Screen | 7-inch color touchscreen |
| Language | Chinese / English |
| Light Source | LED |
| Absorbance Range | 0-3 A |
| Optical Stability | ≤±0.003 A (20 min) |
| Printer | Built-in printer |
| Electrode Options | pH/ORP, conductivity, dissolved oxygen, COD, turbidity, suspended solids, chlorophyll, blue-green algae, etc. |
| Data Transfer | Type-C |
| Battery Capacity | 24V/22.5Ah lithium battery |
| Charging | AC 220V |
| Operating Environment | Temperature 5~40°C, relative humidity ≤85% |
| Low-Range COD | CODcr 0.7-40 mg/L |
| User-defined Curves | Supported |
| Sample Vessels | Φ16 mm, Φ25 mm |
| Features | Same as MP5200 plus low-range COD and pre-made reagent markers (TP, TN) |
| Applications | Clean water samples: drinking water, surface water, groundwater |
| Certifications | Manufactured under ISO 9001 QMS · CE/RoHS/FDA compliance varies by model (certificates available upon request) |
Ang MP5300 ay isang multi-parameter water quality analyzer na dalubhasa sa low-range COD. Itinayo sa dual-zone 8-well digester at colorimetric photometer platform, sinusukat nito ang CODcr mula 0.7 hanggang 40 mg/L, ang working range para sa malinis na tubig kabilang ang inuming tubig, tubig pang-ibabaw at tubig sa lupa.
Idinidi-digest ng built-in programs ang CODcr (2 h), CODcr (fast), CODMn, total phosphorus at total nitrogen; ang pre-made reagent markers para sa total phosphorus at total nitrogen ay nakababawas ng manual preparation. Ang opsyonal na electrodes ay nagdaragdag ng pH, ORP, conductivity, dissolved oxygen, turbidity at suspended solids sa parehong platform; kumpleto ang workflow sa 7-inch touchscreen, built-in printer at Type-C export.
Ano ang pinagkaiba ng MP5300 sa standard COD analyzer?
Ang colorimetric channel nito ay naka-calibrate para sa CODcr 0.7–40 mg/L, kaya direktang sinusukat ang malinis na tubig nang hindi kailangang i-dilute para bagayan ang high-range method.
Nakakapag-digest pa ba ito ng total phosphorus at total nitrogen?
Oo. Sinasaklaw ng built-in programs ang CODcr (2 h), CODcr (fast), CODMn, total phosphorus at total nitrogen; nakababawas ng reagent preparation ang pre-made reagent markers.
Maaari bang ikabit ang pH, conductivity o dissolved oxygen electrodes?
Oo. Kumokonekta ang pH/ORP, conductivity, dissolved oxygen, turbidity at suspended-solids electrodes sa parehong instrumento katabi ng photometric channels.
Saan pinaka-angkop ang MP5300 sa water-supply workflow?
Sa mga programang inuming tubig, tubig pang-ibabaw at tubig sa lupa, ang routine COD checks ay dini-digest, sinusukat, piniprint at inie-export sa iisang portable instrumento nang hindi nagpapadala ng samples.
